50TRV47M8X10.5
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 47UF 20% 50V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet 50TRV47M8X10.5 Datasheet
-
ECAD Model
- Share
In Stock: 82,636
Can ship immediately
Pricing:
- 1$0.84
- 500$0.30423
- 1,000$0.25619
- 2,500$0.24018
- 5,000$0.22417
- 12,500$0.21296
- 25,000$0.20815
- 50,000$0.20415
Quote It
Technical Details
- Series:TRV
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:47 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:8000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:175 mA @ 120 Hz
- Ripple Current @ High Frequency:350 mA @ 100 kHz
- Impedance:360 mOhms
- Lead Spacing:-
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.413" (10.50mm)
- Surface Mount Land Size:0.327" L x 0.327" W (8.30mm x 8.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
