EEU-FC2A120
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 12UF 20% 100V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-FC2A120 Datasheet
-
ECAD Model
- Share
In Stock: 148
Can ship immediately
Pricing:
- 1$0.4
- 10$0.28
- 100$0.16766
- 500$0.12573
- 1,000$0.10618
- 2,500$0.10059
- 5,000$0.09501
Quote It
Technical Details
- Series:FC
- Package:Bulk
- Part Status:Active
- Capacitance:12 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:74.1 mA @ 120 Hz
- Ripple Current @ High Frequency:114 mA @ 100 kHz
- Impedance:1.8 Ohms
- Lead Spacing:0.098" (2.50mm)
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.480" (12.20mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
