AFK336M2AG24T-F
Cornell Dubilier Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 33UF 20% 100V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet AFK336M2AG24T-F Datasheet
-
ECAD Model
- Share
In Stock: 169
Can ship immediately
Pricing:
- 1$1.49
- 500$0.57391
- 1,000$0.50639
- 2,500$0.47263
- 5,000$0.45913
Quote It
Technical Details
- Series:AFK
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:33 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):700mOhm @ 100kHz
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive, Bypass, Decoupling
- Ripple Current @ Low Frequency:150 mA @ 120 Hz
- Ripple Current @ High Frequency:200 mA @ 100 kHz
- Impedance:700 mOhms
- Lead Spacing:-
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.413" (10.50mm)
- Surface Mount Land Size:0.406" L x 0.473" W (10.30mm x 12.00mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
