EKXJ161ELL560MJ20S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 56UF 20% 160V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EKXJ161ELL560MJ20S Datasheet
-
ECAD Model
- Share
In Stock: 119
Can ship immediately
Pricing:
- 1$0.94
- 10$0.72607
- 100$0.53418
- 500$0.42527
- 1,000$0.37341
- 2,500$0.35267
- 5,000$0.3371
Quote It
Technical Details
- Series:KXJ
- Package:Bulk
- Part Status:Active
- Capacitance:56 µF
- Tolerance:±20%
- Voltage - Rated:160 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:315 mA @ 120 Hz
- Ripple Current @ High Frequency:787.5 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.846" (21.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
