EEU-FS1K221
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 220UF 20% 80V THRU HOLE
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-FS1K221 Datasheet
-
ECAD Model
- Share
In Stock: 176
Can ship immediately
Pricing:
- 1$1.09
- 10$0.82955
- 100$0.59353
- 500$0.45952
- 1,000$0.3957
- 2,500$0.37016
- 5,000$0.35102
Quote It
Technical Details
- Series:FS
- Package:Bulk
- Part Status:Active
- Capacitance:220 µF
- Tolerance:±20%
- Voltage - Rated:80 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:784 mA @ 120 Hz
- Ripple Current @ High Frequency:1.12 A @ 100 kHz
- Impedance:54 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
