UCS2G470MHD6TN
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 47UF 20% 400V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UCS2G470MHD6TN Datasheet
-
ECAD Model
- Share
In Stock: 200
Can ship immediately
Pricing:
- 1$2.49
- 250$1.08945
- 500$0.96838
- 750$0.90786
- 1,250$0.84733
- 2,500$0.81708
- 6,250$0.78681
- 12,500$0.75654
Quote It
Technical Details
- Series:UCS
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:47 µF
- Tolerance:±20%
- Voltage - Rated:400 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:590 mA @ 120 Hz
- Ripple Current @ High Frequency:1.18 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):0.846" (21.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
