UHE2A221MHD6
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 220UF 20% 100V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UHE2A221MHD6 Datasheet
-
ECAD Model
- Share
In Stock: 151
Can ship immediately
Pricing:
- 1$1.46
- 10$1.14845
- 100$0.86163
- 500$0.651
- 1,000$0.5744
- 2,500$0.5361
- 5,000$0.5208
Quote It
Technical Details
- Series:UHE
- Package:Bulk
- Part Status:Active
- Capacitance:220 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:791 mA @ 120 Hz
- Ripple Current @ High Frequency:1.13 A @ 100 kHz
- Impedance:91 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.787" (20.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
