EEU-EE2D101S
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 100UF 20% 200V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-EE2D101S Datasheet
-
ECAD Model
- Share
In Stock: 123
Can ship immediately
Pricing:
- 1$2.01
- 10$1.58733
- 100$1.19084
- 500$0.89974
- 1,000$0.79389
- 2,500$0.74097
- 5,000$0.7198
Quote It
Technical Details
- Series:EE
- Package:Bulk
- Part Status:Active
- Capacitance:100 µF
- Tolerance:±20%
- Voltage - Rated:200 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:666 mA @ 120 Hz
- Ripple Current @ High Frequency:1.665 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
