EEV-EB2W100SM
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 10UF 20% 450V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEV-EB2W100SM Datasheet
-
ECAD Model
- Share
In Stock: 178
Can ship immediately
Pricing:
- 1$2.91
- 125$2.02101
- 250$1.73231
- 625$1.53983
- 875$1.44359
- 1,250$1.34735
- 3,125$1.30885
Quote It
Technical Details
- Series:EB
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:10 µF
- Tolerance:±20%
- Voltage - Rated:450 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:155 mA @ 120 Hz
- Ripple Current @ High Frequency:310 mA @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):0.669" (17.00mm)
- Surface Mount Land Size:0.748" L x 0.748" W (19.00mm x 19.00mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
