EEA-GA1V6R8B
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 6.8UF 20% 35V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEA-GA1V6R8B Datasheet
-
ECAD Model
- Share
In Stock: 198
Can ship immediately
Pricing:
- 1$0.3
- 2,000$0.05417
- 4,000$0.04924
- 10,000$0.04678
- 14,000$0.04432
- 50,000$0.03939
- 100,000$0.03324
Quote It
Technical Details
- Series:GA
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:6.8 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:33 mA @ 120 Hz
- Ripple Current @ High Frequency:51.15 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.157" Dia (4.00mm)
- Height - Seated (Max):0.276" (7.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
