UMV1H2R2MFD1TP
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 2.2UF 20% 50V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UMV1H2R2MFD1TP Datasheet
-
ECAD Model
- Share
In Stock: 143
Can ship immediately
Pricing:
- 1$0.49
- 2,000$0.11072
- 4,000$0.10457
- 10,000$0.09842
- 14,000$0.09534
- 50,000$0.08611
- 100,000$0.08365
Quote It
Technical Details
- Series:UMV
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:2.2 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:11 mA @ 120 Hz
- Ripple Current @ High Frequency:16.5 mA @ 10 kHz
- Impedance:-
- Lead Spacing:0.059" (1.50mm)
- Size / Dimension:0.157" Dia (4.00mm)
- Height - Seated (Max):0.236" (6.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
