EEU-FC2A330B
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 33UF 20% 100V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-FC2A330B Datasheet
-
ECAD Model
- Share
In Stock: 100
Can ship immediately
Pricing:
- 1$0.65
- 500$0.20485
- 1,000$0.17413
- 2,500$0.16388
- 5,000$0.15364
- 12,500$0.14084
- 25,000$0.13828
- 50,000$0.13316
Quote It
Technical Details
- Series:FC
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:33 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:198.9 mA @ 120 Hz
- Ripple Current @ High Frequency:306 mA @ 100 kHz
- Impedance:530 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.531" (13.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
