16TZV680M10X10.5
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 680UF 20% 16V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet 16TZV680M10X10.5 Datasheet
-
ECAD Model
- Share
In Stock: 155
Can ship immediately
Pricing:
- 1$0.87
- 500$0.27234
- 1,000$0.23149
- 2,500$0.21788
- 5,000$0.20426
- 12,500$0.18724
- 25,000$0.18383
- 50,000$0.17702
Quote It
Technical Details
- Series:TZV
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:680 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:510 mA @ 120 Hz
- Ripple Current @ High Frequency:850 mA @ 100 kHz
- Impedance:80 mOhms
- Lead Spacing:-
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.413" (10.50mm)
- Surface Mount Land Size:0.406" L x 0.406" W (10.30mm x 10.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
