ULR2C150MNL1GS
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 15UF 20% 160V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet ULR2C150MNL1GS Datasheet
-
ECAD Model
- Share
In Stock: 126
Can ship immediately
Pricing:
- 1$0.78
- 500$0.28178
- 1,000$0.23729
- 2,500$0.22246
- 5,000$0.20763
- 12,500$0.19725
- 25,000$0.1928
- 50,000$0.18909
Quote It
Technical Details
- Series:ULR
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:15 µF
- Tolerance:±20%
- Voltage - Rated:160 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:50 mA @ 120 Hz
- Ripple Current @ High Frequency:80 mA @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.433" (11.00mm)
- Surface Mount Land Size:0.327" L x 0.327" W (8.30mm x 8.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
