EEU-ED2G100B
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 10UF 20% 400V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-ED2G100B Datasheet
-
ECAD Model
- Share
In Stock: 142
Can ship immediately
Pricing:
- 1$0.89
- 500$0.32467
- 1,000$0.27341
- 2,500$0.25632
- 5,000$0.23923
- 12,500$0.22727
- 25,000$0.22214
Quote It
Technical Details
- Series:ED
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:10 µF
- Tolerance:±20%
- Voltage - Rated:400 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:8000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:120 mA @ 120 Hz
- Ripple Current @ High Frequency:300 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
