UVP1V331MHD1TO
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 330UF 20% 35V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UVP1V331MHD1TO Datasheet
-
ECAD Model
- Share
In Stock: 187
Can ship immediately
Pricing:
- 1$1.14
- 500$0.39647
- 1,000$0.3414
- 2,500$0.31938
- 5,000$0.30286
- 12,500$0.287
- 25,000$0.28084
Quote It
Technical Details
- Series:UVP
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:330 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Bi-Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:505 mA @ 120 Hz
- Ripple Current @ High Frequency:757.5 mA @ 10 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
