UPS2A331MHD1TN
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 330UF 20% 100V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPS2A331MHD1TN Datasheet
-
ECAD Model
- Share
In Stock: 232
Can ship immediately
Pricing:
- 1$1.36
- 250$0.59233
- 500$0.50349
- 750$0.47387
- 1,250$0.44425
- 2,500$0.41463
- 6,250$0.39983
- 12,500$0.37761
- 25,000$0.37021
Quote It
Technical Details
- Series:UPS
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:330 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:766.8 mA @ 120 Hz
- Ripple Current @ High Frequency:1.08 A @ 100 kHz
- Impedance:90 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
