860010778020
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP 470 UF 20% 63 V
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 246
Can ship immediately
Pricing:
- 1$1.11
- 300$0.77987
- 600$0.68787
- 1,500$0.65787
Quote It
Technical Details
- Series:WCAP-ATG8
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:470 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:968 mA @ 120 Hz
- Ripple Current @ High Frequency:1.33584 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.512" Dia (13.00mm)
- Height - Seated (Max):0.846" (21.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
