UHV1V561MPD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 560UF 20% 35V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UHV1V561MPD Datasheet
-
ECAD Model
- Share
In Stock: 126
Can ship immediately
Pricing:
- 1$0.78
- 10$0.57525
- 100$0.39412
- 500$0.312
- 1,000$0.26274
- 2,500$0.24632
- 5,000$0.22989
Quote It
Technical Details
- Series:UHV
- Package:Bulk
- Part Status:Active
- Capacitance:560 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:6000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.08 A @ 120 Hz
- Ripple Current @ High Frequency:2.16 A @ 100 kHz
- Impedance:19 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
