UCA2G330MHD6TN
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 33UF 20% 400V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UCA2G330MHD6TN Datasheet
-
ECAD Model
- Share
In Stock: 270
Can ship immediately
Pricing:
- 1$1.77
- 250$0.84813
- 500$0.72092
- 750$0.67851
- 1,250$0.6361
- 2,500$0.59369
- 6,250$0.57673
Quote It
Technical Details
- Series:UCA
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:33 µF
- Tolerance:±20%
- Voltage - Rated:400 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:12000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:320 mA @ 120 Hz
- Ripple Current @ High Frequency:640 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):0.846" (21.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
