EEV-TG1V331Q
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 330UF 20% 35V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEV-TG1V331Q Datasheet
-
ECAD Model
- Share
In Stock: 140
Can ship immediately
Pricing:
- 1$1.76
- 200$0.94618
- 400$0.84105
- 600$0.7149
- 1,000$0.63079
- 2,000$0.58874
- 5,000$0.57192
Quote It
Technical Details
- Series:TG
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:330 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):120mOhm @ 100kHz
- Lifetime @ Temp.:2000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:520 mA @ 120 Hz
- Ripple Current @ High Frequency:800 mA @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.531" (13.50mm)
- Surface Mount Land Size:0.531" L x 0.531" W (13.50mm x 13.50mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
