EMVE630ARA221MKE0S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 220UF 20% 63V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet EMVE630ARA221MKE0S Datasheet
-
ECAD Model
- Share
In Stock: 209
Can ship immediately
Pricing:
- 1$2.13
- 250$1.06784
- 500$0.90765
- 750$0.85426
- 1,250$0.80086
- 2,500$0.74747
- 6,250$0.72078
- 12,500$0.69154
Quote It
Technical Details
- Series:Alchip™- MVE
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:220 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:470 mA @ 120 Hz
- Ripple Current @ High Frequency:-
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.531" (13.50mm)
- Surface Mount Land Size:0.512" L x 0.512" W (13.00mm x 13.00mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
