EKYB630ELL391MJ30S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 390UF 20% 63V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EKYB630ELL391MJ30S Datasheet
-
ECAD Model
- Share
In Stock: 135
Can ship immediately
Pricing:
- 1$1.16
- 10$0.87424
- 100$0.6182
- 500$0.50155
- 1,000$0.43159
- 2,500$0.40825
- 5,000$0.38492
Quote It
Technical Details
- Series:KYB
- Package:Bulk
- Part Status:Active
- Capacitance:390 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:890 mA @ 120 Hz
- Ripple Current @ High Frequency:1.78 A @ 100 kHz
- Impedance:40 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):1.240" (31.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
