UPW1H561MHD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 560UF 20% 50V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPW1H561MHD Datasheet
-
ECAD Model
- Share
In Stock: 251
Can ship immediately
Pricing:
- 1$1.18
- 10$0.9012
- 100$0.64472
- 500$0.49914
- 1,000$0.42982
- 2,500$0.40208
- 5,000$0.38129
Quote It
Technical Details
- Series:UPW
- Package:Bulk
- Part Status:Active
- Capacitance:560 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:7000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.374 A @ 120 Hz
- Ripple Current @ High Frequency:1.832 A @ 100 kHz
- Impedance:50 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.984" (25.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
