ELXZ630ELL331MJ30S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 330UF 20% 63V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet ELXZ630ELL331MJ30S Datasheet
-
ECAD Model
- Share
In Stock: 155
Can ship immediately
Pricing:
- 1$1.19
- 10$0.87214
- 100$0.59751
- 500$0.47303
- 1,000$0.39834
- 2,500$0.37344
- 5,000$0.34854
Quote It
Technical Details
- Series:LXZ
- Package:Bulk
- Part Status:Active
- Capacitance:330 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:650 mA @ 120 Hz
- Ripple Current @ High Frequency:1.3 A @ 100 kHz
- Impedance:90 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):1.240" (31.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
