UCY2D151MHD3TN
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 150UF 20% 200V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UCY2D151MHD3TN Datasheet
-
ECAD Model
- Share
In Stock: 119
Can ship immediately
Pricing:
- 1$2.29
- 250$1.10409
- 500$0.98142
- 750$0.92009
- 1,250$0.85874
- 2,500$0.82807
- 6,250$0.7974
- 12,500$0.76673
Quote It
Technical Details
- Series:UCY
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:150 µF
- Tolerance:±20%
- Voltage - Rated:200 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:12000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:945 mA @ 120 Hz
- Ripple Current @ High Frequency:1.89 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.043" (26.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
