UUG2C101MNQ1MS
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 100UF 20% 160V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UUG2C101MNQ1MS Datasheet
-
ECAD Model
- Share
In Stock: 175
Can ship immediately
Pricing:
- 1$1.99
- 125$1.11951
- 250$0.9596
- 625$0.85298
- 875$0.79967
- 1,250$0.74635
- 3,125$0.7197
- 6,250$0.69304
- 12,500$0.66639
Quote It
Technical Details
- Series:UUG
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:100 µF
- Tolerance:±20%
- Voltage - Rated:160 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:590 mA @ 120 Hz
- Ripple Current @ High Frequency:944 mA @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):0.689" (17.50mm)
- Surface Mount Land Size:0.752" L x 0.752" W (19.10mm x 19.10mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
