UPZ2W180MPD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 18UF 20% 450V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPZ2W180MPD Datasheet
-
ECAD Model
- Share
In Stock: 201
Can ship immediately
Pricing:
- 1$1.29
- 10$1.01849
- 100$0.76429
- 500$0.57745
- 1,000$0.50951
- 2,500$0.47554
- 5,000$0.46196
Quote It
Technical Details
- Series:UPZ
- Package:Bulk
- Part Status:Active
- Capacitance:18 µF
- Tolerance:±20%
- Voltage - Rated:450 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:-
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:180 mA @ 120 Hz
- Ripple Current @ High Frequency:270 mA @ 10 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):1.319" (33.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
