EMVH101ARA680MKG5S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 68UF 20% 100V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet EMVH101ARA680MKG5S Datasheet
-
ECAD Model
- Share
In Stock: 171
Can ship immediately
Pricing:
- 1$2.18
- 200$1.36777
- 400$1.19316
- 600$1.07675
- 1,000$0.96035
- 2,000$0.93125
- 5,000$0.90214
- 10,000$0.88759
Quote It
Technical Details
- Series:Alchip™- MVH
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:68 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):260mOhm @ 100kHz
- Lifetime @ Temp.:5000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:-
- Applications:Automotive
- Ripple Current @ Low Frequency:220 mA @ 120 Hz
- Ripple Current @ High Frequency:550 mA @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.630" (16.00mm)
- Surface Mount Land Size:0.512" L x 0.512" W (13.00mm x 13.00mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
