UCZ1H681MNQ1MS
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 680UF 20% 50V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UCZ1H681MNQ1MS Datasheet
-
ECAD Model
- Share
In Stock: 159
Can ship immediately
Pricing:
- 1$2.32
- 125$1.30313
- 250$1.11699
- 625$0.99288
- 875$0.93082
- 1,250$0.86877
- 3,125$0.83774
- 6,250$0.80671
- 12,500$0.77568
Quote It
Technical Details
- Series:UCZ
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:680 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):78mOhm @ 100kHz
- Lifetime @ Temp.:3500 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.05 A @ 120 Hz
- Ripple Current @ High Frequency:2.1 A @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):0.689" (17.50mm)
- Surface Mount Land Size:0.752" L x 0.752" W (19.10mm x 19.10mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
