EEU-TA1V471S
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 470UF 20% 35V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-TA1V471S Datasheet
-
ECAD Model
- Share
In Stock: 178
Can ship immediately
Pricing:
- 1$1.83
- 10$1.44674
- 100$1.08511
- 500$0.81982
- 1,000$0.72337
- 2,500$0.67514
- 5,000$0.65585
Quote It
Technical Details
- Series:TA
- Package:Bulk
- Part Status:Active
- Capacitance:470 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.088 A @ 120 Hz
- Ripple Current @ High Frequency:1.45 A @ 100 kHz
- Impedance:88 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.650" (16.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
