EKXJ201ELL151MK35S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 150UF 20% 200V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EKXJ201ELL151MK35S Datasheet
-
ECAD Model
- Share
In Stock: 163
Can ship immediately
Pricing:
- 1$1.94
- 10$1.55739
- 100$1.19827
- 500$0.93463
- 1,000$0.83876
- 2,500$0.79083
- 5,000$0.76686
Quote It
Technical Details
- Series:KXJ
- Package:Bulk
- Part Status:Active
- Capacitance:150 µF
- Tolerance:±20%
- Voltage - Rated:200 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:12000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:860 mA @ 120 Hz
- Ripple Current @ High Frequency:1.935 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):1.437" (36.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
