80ZLH820MEFC18X25
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 820UF 20% 80V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet 80ZLH820MEFC18X25 Datasheet
-
ECAD Model
- Share
In Stock: 183
Can ship immediately
Pricing:
- 1$2
- 10$1.62099
- 100$1.23801
- 500$0.9432
- 1,000$0.8253
- 2,500$0.79582
- 5,000$0.76635
Quote It
Technical Details
- Series:ZLH
- Package:Bulk
- Part Status:Active
- Capacitance:820 µF
- Tolerance:±20%
- Voltage - Rated:80 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.362 A @ 120 Hz
- Ripple Current @ High Frequency:-
- Impedance:38 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
