EEE-TP1J751V
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 750UF 20% 63V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEE-TP1J751V Datasheet
-
ECAD Model
- Share
In Stock: 137
Can ship immediately
Pricing:
- 1$3.09
- 125$3.09
- 250$2.6486
- 625$2.35433
- 875$2.20718
- 1,250$2.06003
- 3,125$1.98645
- 6,250$1.91288
Quote It
Technical Details
- Series:TP, Anti-Vibration
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:750 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):95mOhm @ 100kHz
- Lifetime @ Temp.:3000 Hrs @ 125°C
- Operating Temperature:-55°C ~ 125°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive, High Temperature Reflow
- Ripple Current @ Low Frequency:1.5 A @ 120 Hz
- Ripple Current @ High Frequency:2 A @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):0.669" (17.00mm)
- Surface Mount Land Size:0.748" L x 0.748" W (19.00mm x 19.00mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
