UBX2D680MHL1TN
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 68UF 20% 200V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UBX2D680MHL1TN Datasheet
-
ECAD Model
- Share
In Stock: 111
Can ship immediately
Pricing:
- 1$4.96
- 250$2.70488
- 500$2.52455
- 750$2.45242
Quote It
Technical Details
- Series:UBX
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:68 µF
- Tolerance:±20%
- Voltage - Rated:200 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 150°C
- Operating Temperature:-40°C ~ 150°C
- Polarization:Polar
- Ratings:-
- Applications:Automotive
- Ripple Current @ Low Frequency:290 mA @ 120 Hz
- Ripple Current @ High Frequency:435 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.043" (26.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
