B43504A9157M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 150UF 20% 400V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet B43504A9157M000 Datasheet
-
ECAD Model
- Share
In Stock: 476
Can ship immediately
Pricing:
- 1$4.74
- 10$4.2639
- 100$3.22163
- 500$2.65308
- 1,000$2.57728
Quote It
Technical Details
- Series:B43504
- Package:Bulk
- Part Status:Not For New Designs
- Capacitance:150 µF
- Tolerance:±20%
- Voltage - Rated:400 V
- ESR (Equivalent Series Resistance):590mOhm @ 100Hz
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:820 mA @ 100 Hz
- Ripple Current @ High Frequency:-
- Impedance:730 mOhms
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:0.866" Dia (22.00mm)
- Height - Seated (Max):1.654" (42.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
