UVZ2DR47MED1TD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 0.47UF 20% 200V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UVZ2DR47MED1TD Datasheet
-
ECAD Model
- Share
In Stock: 170
Can ship immediately
Pricing:
- 1$0.33
- 2,000$0.06877
- 4,000$0.06362
- 10,000$0.06018
- 14,000$0.05708
- 50,000$0.05158
- 100,000$0.04556
Quote It
Technical Details
- Series:UVZ
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:0.47 µF
- Tolerance:±20%
- Voltage - Rated:200 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:11 mA @ 120 Hz
- Ripple Current @ High Frequency:17.6 mA @ 10 kHz
- Impedance:-
- Lead Spacing:0.098" (2.50mm)
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.492" (12.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
