865060257010
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP 1000 UF 20% 10 V
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 195
Can ship immediately
Pricing:
- 1$0.93
- 500$0.5743
- 1,000$0.5493
Quote It
Technical Details
- Series:WCAP-ASLL
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:1000 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:448.5 mA @ 120 Hz
- Ripple Current @ High Frequency:690 mA @ 100 kHz
- Impedance:90 mOhms
- Lead Spacing:-
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.413" (10.50mm)
- Surface Mount Land Size:0.406" L x 0.406" W (10.30mm x 10.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
