10YXJ1000M10X12.5
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1000UF 20% 10V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet 10YXJ1000M10X12.5 Datasheet
-
ECAD Model
- Share
In Stock: 161
Can ship immediately
Pricing:
- 1$0.58
- 10$0.40941
- 100$0.26931
- 500$0.19948
- 1,000$0.16956
- 2,500$0.15958
- 5,000$0.14961
Quote It
Technical Details
- Series:YXJ
- Package:Bulk
- Part Status:Active
- Capacitance:1000 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:8000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:648.75 mA @ 120 Hz
- Ripple Current @ High Frequency:865 mA @ 100 kHz
- Impedance:80 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.551" (14.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
