ESMG101ELL220MHB5D
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 22UF 20% 100V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet ESMG101ELL220MHB5D Datasheet
-
ECAD Model
- Share
In Stock: 150
Can ship immediately
Pricing:
- 1$0.75
- 10$0.52644
- 100$0.34658
- 500$0.25673
- 1,000$0.21822
- 2,500$0.20539
- 5,000$0.19255
Quote It
Technical Details
- Series:SMG
- Package:Bulk
- Part Status:Active
- Capacitance:22 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:130 mA @ 120 Hz
- Ripple Current @ High Frequency:234 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.512" (13.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
