UHW2A271MHD6TN
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 270UF 20% 100V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UHW2A271MHD6TN Datasheet
-
ECAD Model
- Share
In Stock: 213
Can ship immediately
Pricing:
- 1$2.06
- 250$0.99231
- 500$0.88206
- 750$0.82693
- 1,250$0.7718
- 2,500$0.74424
- 6,250$0.71667
- 12,500$0.68911
Quote It
Technical Details
- Series:UHW
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:270 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:975 mA @ 120 Hz
- Ripple Current @ High Frequency:1.95 A @ 100 kHz
- Impedance:50 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
