100SEV220M16X21.5
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 220UF 20% 100V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet 100SEV220M16X21.5 Datasheet
-
ECAD Model
- Share
In Stock: 138
Can ship immediately
Pricing:
- 1$2.26
- 75$1.44779
- 150$1.26678
- 375$1.0858
- 525$0.96516
- 750$0.90483
- 1,875$0.84451
- 3,750$0.81435
- 7,500$0.78419
Quote It
Technical Details
- Series:SEV
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:220 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:665 mA @ 120 Hz
- Ripple Current @ High Frequency:798 mA @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:0.669" L x 0.669" W (17.00mm x 17.00mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
