UHW1E182MHD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1800UF 20% 25V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UHW1E182MHD Datasheet
-
ECAD Model
- Share
In Stock: 117
Can ship immediately
Pricing:
- 1$1.79
- 10$1.41135
- 100$1.05874
- 500$0.79997
- 1,000$0.70585
- 2,500$0.65879
- 5,000$0.63997
Quote It
Technical Details
- Series:UHW
- Package:Bulk
- Part Status:Active
- Capacitance:1800 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.92 A @ 120 Hz
- Ripple Current @ High Frequency:3.2 A @ 100 kHz
- Impedance:15 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
