16TGV2200M16X21.5
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 2200UF 20% 16V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet 16TGV2200M16X21.5 Datasheet
-
ECAD Model
- Share
In Stock: 176
Can ship immediately
Pricing:
- 1$2.81
- 75$1.80188
- 150$1.5766
- 375$1.35136
- 525$1.20122
- 750$1.12614
- 1,875$1.05107
- 3,750$1.01353
- 7,500$0.97599
Quote It
Technical Details
- Series:TGV
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:2200 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):41mOhm @ 100kHz
- Lifetime @ Temp.:5000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:990 mA @ 120 Hz
- Ripple Current @ High Frequency:1.65 A @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:0.669" L x 0.669" W (17.00mm x 17.00mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
