EEE-TP70821M
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 820UF 20% 70V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEE-TP70821M Datasheet
-
ECAD Model
- Share
In Stock: 188
Can ship immediately
Pricing:
- 1$2.92
- 75$2.43229
- 150$2.12822
- 375$1.82417
- 525$1.62149
- 750$1.52015
- 1,875$1.4188
- 3,750$1.36813
- 7,500$1.31745
Quote It
Technical Details
- Series:TP
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:820 µF
- Tolerance:±20%
- Voltage - Rated:70 V
- ESR (Equivalent Series Resistance):68mOhm @ 100kHz
- Lifetime @ Temp.:4000 Hrs @ 125°C
- Operating Temperature:-55°C ~ 125°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive, High Temperature Reflow
- Ripple Current @ Low Frequency:1.95 A @ 120 Hz
- Ripple Current @ High Frequency:2.6 A @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:0.748" L x 0.748" W (19.00mm x 19.00mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
