UCX1H102MNS1ZD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1000UF 20% 50V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UCX1H102MNS1ZD Datasheet
-
ECAD Model
- Share
In Stock: 186
Can ship immediately
Pricing:
- 1$3.34
- 60$2.35951
- 120$2.06456
- 540$1.57298
- 1,020$1.37635
- 2,520$1.32721
- 5,040$1.27805
Quote It
Technical Details
- Series:UCX
- Package:Tray
- Part Status:Active
- Capacitance:1000 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):50mOhm
- Lifetime @ Temp.:2000 Hrs @ 135°C
- Operating Temperature:-40°C ~ 135°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:800 mA @ 120 Hz
- Ripple Current @ High Frequency:1.6 A @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:0.673" L x 0.673" W (17.10mm x 17.10mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
