UCX1V152MNS6ZD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1500UF 20% 35V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UCX1V152MNS6ZD Datasheet
-
ECAD Model
- Share
In Stock: 156
Can ship immediately
Pricing:
- 1$3.46
- 60$2.43962
- 120$2.13462
- 540$1.62642
- 1,020$1.42311
- 2,520$1.37228
- 5,040$1.32146
Quote It
Technical Details
- Series:UCX
- Package:Tray
- Part Status:Active
- Capacitance:1500 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):40mOhm
- Lifetime @ Temp.:2000 Hrs @ 135°C
- Operating Temperature:-40°C ~ 135°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:950 mA @ 120 Hz
- Ripple Current @ High Frequency:1.9 A @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:0.673" L x 0.673" W (17.10mm x 17.10mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
