ALC40A221EC500

Technical Details

• Series:ALC40
• Package:Box
• Part Status:Active
• Capacitance:220 µF
• Tolerance:±20%
• Voltage - Rated:500 V
• ESR (Equivalent Series Resistance):1.02Ohm @ 100Hz
• Lifetime @ Temp.:9000 Hrs @ 105°C
• Operating Temperature:-40°C ~ 105°C
• Polarization:Polar
• Ratings:-

• Applications:General Purpose
• Ripple Current @ Low Frequency:2.03 A @ 100 Hz
• Ripple Current @ High Frequency:4.09 A @ 10 kHz
• Impedance:820 mOhms
• Lead Spacing:0.394" (10.00mm)
• Size / Dimension:1.575" Dia (40.00mm)
• Height - Seated (Max):1.378" (35.00mm)
• Surface Mount Land Size:-
• Mounting Type:Through Hole
• Package / Case:Radial, Can - Snap-In
