UCM1H471MNJ1MS
Nichicon- Lifecycle status Active
- RoHS RoHS Compliant
- Description50V 470UF 20% CHIP TYPE, ALUMINU
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 149
Can ship immediately
Pricing:
- 1$2.02
Quote It
Technical Details
- Series:UCM
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:470 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:670 mA @ 120 Hz
- Ripple Current @ High Frequency:1.34 A @ 100 kHz
- Impedance:120 mOhms
- Lead Spacing:-
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.571" (14.50mm)
- Surface Mount Land Size:0.535" L x 0.535" W (13.60mm x 13.60mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
