UCZ1J561MNS1MS
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 560UF 20% 63V SMD
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 104
Can ship immediately
Pricing:
- 1$2.89
Quote It
Technical Details
- Series:UCZ
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:560 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):70mOhm @ 100kHz
- Lifetime @ Temp.:4000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.25 A @ 120 Hz
- Ripple Current @ High Frequency:2.5 A @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.886" (22.50mm)
- Surface Mount Land Size:0.673" L x 0.673" W (17.10mm x 17.10mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
